Specification
| Model | ZENITH ALPHA (L size) 單軌 | ZENITH ALPHA (L size) 雙軌 |
| PCB Size | 50×50~490×510mm | 50×50~490×580mm 單軌模式 50×50~490×320mm 雙軌模式 |
| Board Thickness | 0.4~5mm | 0.4~5mm |
| Power Supply | 200~240VAC, 50/60Hz | 200~240VAC, 50/60Hz |
| Air Pressure | 5kgf/cm2 (0.45MPa) | 5kgf/cm2 (0.45MPa) |
| 設備尺寸 | 1000×1295×1627mm | 1000×1495×1627mm |
| Weight | 600kg | 700kg |
| Model | ZENITH ALPHA (XL size) 單軌 | ZENITH ALPHA (XL size) 雙軌 |
| PCB Size | 50×50~690×690mm | 50×50~690×580mm 單軌模式 50×50~690×320mm 雙軌模式 |
| Board Thickness | 0.4~8mm | 0.4~8mm |
| Power Supply | 200~240VAC, 50/60Hz | 200~240VAC, 50/60Hz |
| Air Pressure | 5kgf/cm2 (0.45MPa) | 5kgf/cm2 (0.45MPa) |
| 設備尺寸 | 1200×1495×1627mm | 1200×1495×1627mm |
| Weight | 750kg | 750kg |
